Karpenter Not Scaling Up Nodes: Causes and Fixes (2026)

When Karpenter is not scaling up nodes, check four gates in order: the Kubernetes scheduler never marked your pod unschedulable, your NodePool or EC2NodeClass is not Ready, a NodePool limit is exceeded, or no instance type satisfies both the pod's and the NodePool's requirements.

TL;DR

Karpenter is not a general-purpose "add capacity" controller. Its own documentation is precise about the trigger: "Karpenter focuses on scheduling pods that the Kubernetes scheduler has marked as unschedulable."¹ Everything downstream of that follows a short, checkable chain — a NodePool that is Ready, an EC2NodeClass it references that is also Ready, limits that have not been hit, and at least one instance type whose offering satisfies the intersection of the pod's requirements and the NodePool's. Break any link and pods sit Pending with no new nodes, sometimes with nothing on the pod that points at the reason. This guide walks the chain in the order that resolves fastest, using the behaviour documented for the Karpenter v1.14 docs line.² One scoping note before you start: karpenter.sh is the AWS provider's documentation site, so EC2NodeClass, EC2 Fleet behaviour, and the VPC CNI specifics below are AWS-only. NodePools, NodeClaims, and the scheduling model are common to every Karpenter provider.

What you'll learn

• How to decide quickly whether Karpenter or kube-scheduler owns your problem — and why both write FailedScheduling events on the same pod
• How to tell "Karpenter is slow" from "Karpenter is stuck", and why a few seconds of nothing is expected
• How to check NodePool and EC2NodeClass readiness, and why an unready NodeClass disables every NodePool that references it
• What happens when spec.limits is exceeded, and how to see current usage
• What no instance type met the scheduling requirements or had a required offering actually means
• Why a pod can be "incompatible" with a NodePool it looks compatible with
• Why topology spread constraints deadlock even when the cluster has spare zones
• Why Karpenter sometimes launches nodes that stay empty and get reaped in a loop
• Why a launched node can still leave your pod Pending or stuck in ContainerCreating
• Why a full ResourceQuota produces no scale-up at all
• Which metrics and log settings to reach for first

Is it Karpenter's problem, or the Kubernetes scheduler's?

Start here, because a pod stuck Pending is not by itself evidence that Karpenter did anything wrong. Karpenter reacts to pods that kube-scheduler has already declared unschedulable¹ — in practice, pods carrying a PodScheduled condition with reason Unschedulable. If nothing has marked your pod that way, Karpenter has nothing to react to. (Worth knowing if you run a second scheduler: one that reports a different reason will not trigger Karpenter at all.)

kubectl describe pod <pod> -n <namespace> | sed -n '/Events/,$p'

Read that output carefully, because two different controllers write FailedScheduling events onto the same pod, and it is easy to read one and stop. kube-scheduler writes the familiar 0/N nodes are available… message explaining why every existing node was rejected. Karpenter writes its own FailedScheduling event explaining why it declined to build a new one, in the form Failed to schedule pod, <reason> — where the reason is a string like nodepool requirements filtered out all available instance types, no instance type met the scheduling requirements or had a required offering, incompatible requirements, did not tolerate taint, node limits have been exhausted for nodepool, or all available instance types exceed limits for nodepool. Several of these append structured detail in parentheses — the taint that was not tolerated, or the NodePool that ran out of room — so grep for the phrase, not the whole line.

That second message is the one to look for, and it is already on screen from the command above. If it is there, it has told you the answer and you can skip most of what follows. The sections below exist for when it is absent, terse, or you want to understand what it means. (These strings are internal to the controller and have been reworded across releases, so match on the shape of the message rather than the exact text — the list above is the v1.14 wording.)

The scheduler's message doubles as a specification: it enumerates why each existing node was rejected — untolerated taint, insufficient CPU, unmatched selector — and Karpenter's job is to build a node that would not draw those rejections.

One caveat on relying on events at all: Kubernetes events are garbage-collected after the API server's --event-ttl, which defaults to one hour, so absence of a FailedScheduling event is not evidence that nothing failed — particularly for the kube-scheduler side. The pod's PodScheduled condition is the durable signal, and it is what Karpenter actually keys on. And Karpenter writes events onto the NodePool as well as the pod — a NoCompatibleInstanceTypes warning lands on the NodePool object, never on the pod — so check both:

kubectl describe nodepool <name> | sed -n '/Events/,$p'

Is Karpenter slow rather than stuck?

Worth ruling out early, because it is indistinguishable from a failure if you are watching a terminal. Karpenter deliberately batches pending pods before provisioning: BATCH_IDLE_DURATION (default 1s) extends the batching window each time a new pending pod arrives, and BATCH_MAX_DURATION (default 10s) caps how long that extension can continue.³ A steady arrival of pending pods will hold the window open to the maximum.

So a scale-up that has not happened after five seconds is not yet evidence of anything. Give it past the batch ceiling, plus EC2 launch and node-registration time, before concluding Karpenter is not scaling up nodes at all.

Is your NodePool actually Ready?

A NodePool that is not Ready is invisible to scheduling, and the pod's own events will not name it as the cause — you have to go and look. The docs are unambiguous: "If a NodePool is not ready, it will not be considered for scheduling."⁴

kubectl get nodepool -o wide
kubectl describe nodepool <name> | sed -n '/Conditions/,$p'

kubectl get nodepool -o wide prints the weight, resource totals and — usefully for the next section — the NodeClass each pool references, so read the real names from there rather than assuming everything is called default.

NodePools carry four status conditions:⁴

That last row needs a caveat, because the docs contradict themselves about it. The table says Ready "will not be true until all the other conditions on nodePool are true," but the paragraph immediately below that table states that NodeRegistrationHealthy is "informational and does not affect the top-level Ready condition."⁴ The second statement is the operative one: a NodePool can report Ready=True while NodeRegistrationHealthy=False is separately telling you a misconfiguration is stopping launched nodes from registering. Read both conditions rather than trusting Ready alone.

And the degenerate case, which is easy to hit in a fresh cluster or after a botched Helm upgrade: "Karpenter won't do anything if there is not at least one NodePool configured."⁴ An empty kubectl get nodepool is a complete explanation.

Is your EC2NodeClass Ready?

Check this even when the NodePool looks fine, because an unready NodeClass disables its NodePools without touching the NodePool's own configuration. Per the NodeClass docs: "If a NodeClass is not ready, NodePools that reference it through their nodeClassRef will not be considered for scheduling."⁵

kubectl get ec2nodeclass
kubectl describe ec2nodeclass <name> | sed -n '/Conditions/,$p'

The condition set is granular, which is what makes it useful — each one names a discovery or validation step that can independently fail:⁵

You do not have to guess which dependency broke: when Ready is false, "Message on the condition indicates the dependency that was not resolved."⁵ A false SubnetsReady or AMIsReady points directly at selector terms whose tags no longer match anything — for example a subnet retagged during a VPC migration.

If you have just changed IAM permissions and the NodeClass still reports stale validation, Karpenter caches validation results; the documented way to force a refresh is to add any annotation to the EC2NodeClass.²

Have you hit the NodePool limits?

spec.limits is a hard stop. Unlike the readiness gates above, this one does announce itself on the pod — the node limits have been exhausted for nodepool and all available instance types exceed limits for nodepool messages from the triage step both come from here, with the offending NodePool named in the structured detail. If you have one of those, you already know the cause and only need the numbers. The documented behaviour: "If a limit has been exceeded, nodes provisioning is prevented until some nodes have been terminated."⁴

kubectl get nodepool -o custom-columns=\
NAME:.metadata.name,LIMITS:.spec.limits,USED:.status.resources,NODES:.status.nodes

The docs' own one-liner for this is kubectl get nodepool -o=jsonpath='{.items[0].status}',⁴ which is fine for a single-pool cluster but reads one arbitrary NodePool and prints no limits to compare against — not what you want on a cluster with several pools. Either way you are comparing status.resources — the CPU, memory and ephemeral-storage the pool has actually provisioned — plus status.nodes against spec.limits. Two adjacent gotchas:

• limits.nodes is separate from the resource limits and "constrains the maximum number of nodes during scaling operations or drift replacement."⁴ A pool can be far under its CPU limit and still be node-capped.
• Limit enforcement is not transactional. The docs state plainly that "limit checking is eventually consistent, which can result in overrun during rapid scale outs."⁴ If you are debugging why a pool went slightly over its limit, that is expected behaviour, not a bug.

If spec.limits is unset there is "no default limitation on resource allocation," and your ceiling becomes your cloud provider's own quotas instead.⁴ That relocates the same symptom to a different console — worth checking EC2 vCPU quotas before concluding Karpenter is at fault.

For Prometheus users, karpenter_nodepools_limit and karpenter_nodepools_usage expose both sides of this comparison, labelled by nodepool name and resource type.⁶

What does "no instance type met the scheduling requirements or had a required offering" mean?

This log line means Karpenter simulated the launch and found nothing to launch. The docs split it into two distinct failures wearing one message.²

The first half — no instance type met the scheduling requirements — is a sizing or filtering problem. A pod may have resource requests that necessitate a minimum instance size, and if the NodePool is confined to a particular instance family and size, nothing may fit. Critically, "resource requests from daemonsets are considered when determining if an instance type is compatible with the pod."² That is the detail that breaks a hand-checked calculation: a pod whose requests fit an allowed instance type on paper can still be rejected, because the DaemonSets that will land on that node are subtracted first.

The second half — or had a required offering — is about availability rather than shape. Karpenter's FAQ defines an offering as "a combination of zone and capacity type" for a given instance type.¹ If a pod is pinned to one availability zone, the instance type must exist there. The docs give the canonical example: a StatefulSet pod with an attached EBS volume whose subnet changed can end up in a different availability zone from the volume it needs, producing a required-offering error.²

Two capacity behaviours shape what you see next. Karpenter prioritises reserved capacity, then spot, then on-demand, falling back "generally within milliseconds" when a higher-priority type is unavailable.⁴ And when the Fleet API reports insufficient capacity, "Karpenter caches that result across all attempts to provision EC2 capacity for that instance type and zone for the next 3 minutes."⁴ That three-minute window is worth knowing about before you start changing configuration: if a retry succeeds a few minutes later, what expired may simply have been a cached unavailability rather than anything you fixed.

Watch karpenter_cloudprovider_instance_launch_failures_total, which breaks CreateFleet failures down by availability zone, zone ID, capacity type, and launch failure reason.⁶

One AWS-account-level prerequisite applies to new accounts and looks exactly like a capacity problem: unless the account has already onboarded to EC2 Spot, the spot service-linked role will not exist and every spot launch fails with AuthFailure.ServiceLinkedRoleCreationNotPermitted. The fix is a single command, aws iam create-service-linked-role --aws-service-name spot.amazonaws.com.² On a NodePool restricted to spot, there is no on-demand fallback to mask it.

Why is my pod "incompatible" with a NodePool that looks compatible?

Compatibility is an intersection, not a similarity. Nodes are chosen using both the NodePool's and the pod's requirements, and the NodePool docs are blunt about the consequence: "If there is no overlap, nodes will not be launched."⁴ Or, as the same page puts it, a pod's requirements must be within the NodePool's. Three things narrow that intersection — and then a fourth failure that wears the same costume without being an intersection problem at all.

Taints. "If Karpenter encounters a taint in the NodePool that is not tolerated by a Pod, Karpenter won't use that NodePool to provision the pod."⁴ That pool is quietly dropped from consideration for this pod; if no other pool can take it either, the pod's Failed to schedule pod event ends with did not tolerate taint and the offending taint in the structured detail.

To confirm and fix, read the pool's taints and then decide which side to change:

kubectl get nodepool <name> -o jsonpath='{.spec.template.spec.taints}'

Either add a matching tolerations entry to the pod spec, or relax spec.template.spec.taints on the NodePool. Which one is correct depends on intent: taints on a NodePool exist to reserve that capacity for particular workloads — the docs' own example taints a GPU pool so that "in order for a pod to run on a node defined in this NodePool, it must tolerate nvidia.com/gpu in its pod spec."⁴ If the reservation is deliberate, tolerate it on the pod. If the taint is vestigial, remove it from the pool — remembering that taints is one of the spec.template fields that feeds the drift hash, so editing it rolls that pool's existing nodes.

Requirements that exclude the pod's nodeSelector. The docs give the direct example: if a pod requests an instance type via nodeSelector and that type is not in the NodePool's instance-type requirements, "Karpenter will not create a node or schedule the pod."⁴

minValues under the default policy. If a requirement sets minValues and Karpenter cannot meet that flexibility minimum, the behaviour depends on --min-values-policy (or MIN_VALUES_POLICY): under Strict it fails the scheduling loop for that NodePool, falling back to another NodePool or failing the pod outright; under BestEffort it relaxes minValues until they can be met.⁴ The trap is that Strict is the default,³ so this applies to you whether or not you configured it — an aggressive minValues is a quiet way to disqualify your only viable pool. Note the corollary: karpenter_nodeclaims_created_total carries a label for "if min values was relaxed for this nodeclaim,"⁶ but under Strict relaxation never happens, so that label only carries signal once you have switched to BestEffort.

An empty instance-type catalogue. This one is not a pod-versus-NodePool problem at all: the NodePool's own requirements can filter out every instance type the provider offers, by stacking constraints such as instance-family, instance-generation, instance-category and capacity-type until nothing satisfies all of them at once. Karpenter reports this per NodePool, as a NoCompatibleInstanceTypes warning event whose message reads "NodePool requirements filtered out all compatible available instance types" — or, when minValues was the culprit, the same message with "due to minValues incompatibility" appended. Crucially that event is attached to the NodePool object, not to the pod, so the object it hangs off is what identifies which pool came back empty.

That attachment is why this cause is so easy to miss. The pod only picks up a matching nodepool requirements filtered out all available instance types reason when every NodePool has been filtered down to nothing. In a cluster with several pools, one pool can empty out completely while another still works, and the pod's events will say nothing about it at all — the only trace is the warning sitting on the NodePool. Check kubectl describe nodepool for each pool you expect to be serving the workload, not just the pod.

When several pools match, the docs are careful to say "there is no ordering guarantee",¹ while also stating that Karpenter uses the NodePool with the highest weight if more than one matches.⁴ Read together: weight is the documented tiebreak when the weights differ, and where they do not, the docs decline to promise anything about which pool wins. The implementation does order equal-weight pools deterministically, but that is not a documented contract — which is why the docs recommend making NodePools mutually exclusive rather than relying on selection order at all.⁴ To pin a workload deliberately, use the node selector karpenter.sh/nodepool: my-nodepool.¹

One thing that is not a scheduling-time incompatibility, despite looking like one: the cap of "a limit of 100 on the total number of requirements on both the NodePool and the NodeClaim," which spec.template.metadata.labels also count toward.⁴ That ceiling is enforced by the CRD schema, so you hit it as a rejected kubectl apply or a failed NodeClaim creation — not as a running NodePool quietly declining your pod.

Why won't Karpenter scale up for my topology spread constraint?

Because pods do not inherit the requirements of the NodePools that could serve them. Karpenter derives a pod's eligible domains from the pod's own requirements, not from the pool that will actually serve it.² Reading the documented example closely, the universe those domains are drawn from spans every NodePool in the cluster — plus zones already represented on existing nodes — rather than only the matching one.

The deadlock appears whenever that universe is wider than the set of zones the pool actually serving the pod can reach. The documented example produces it with two NodePools: a permissive default with topology.kubernetes.io/zone: Exists, able to launch in all three availability zones, alongside np-zonal-constraint, pinned to two. A Deployment with a nodeSelector that only np-zonal-constraint satisfies, and with a zonal topologySpreadConstraint but no zonal nodeAffinity, sees all three zones as eligible domains — because the default pool put the third one in the universe — while the only pool that can serve it covers two.²

The result has a distinctive shape: the first two replicas launch fine, and the third never provisions, because Karpenter "can't provision capacity in the third domain."² The fix is to make the pod's view match the serving NodePool's by adding matching zonal nodeAffinity to the pod spec, or to widen the NodePool.²

This is worth internalising because the naive reading — "my NodePool is missing a zone" — is not by itself the failure. A restricted pool in a cluster with nothing else in that third zone contributes no third domain, so nothing deadlocks. Something else has to be putting that zone into the universe. When you hit this, go looking for what: another NodePool that reaches the zone your serving pool cannot, or existing nodes already sitting there — a managed node group, for instance — since zones represented on current nodes count too.

A related but distinct complaint is spread constraints that provision correctly and then distribute wrongly. That one is a kube-scheduler behaviour: if Karpenter launches nodes that can each hold more than the required number of pods and they become Ready at different times, the scheduler may overfill the first Ready node. The documented preferred solution is the minDomains field in topologySpreadConstraints, "enabled by default starting in Kubernetes 1.27."¹

Why does Karpenter keep launching nodes that stay empty?

This is the startup-taint loop, and it costs real money for as long as it runs. Something — a DaemonSet, a userData script, a networking agent — applies a taint after the node is provisioned. Karpenter then sees that the pending pod cannot schedule to the node it just launched, and provisions another.¹

Usually the taint clears and the extra node is reaped by consolidation. But if it does not clear fast enough, the docs describe the pathological outcome directly: "an infinite loop of nodes being provisioned and consolidated without the pending pod ever scheduling."¹ The NodePool docs put the same warning from the other direction — "Failure to provide accurate startupTaints can result in Karpenter continually provisioning new nodes."⁴

First, find the taint that is actually landing, rather than guessing:

kubectl get node <looping-node> -o jsonpath='{.spec.taints}'

Then declare it in startupTaints on the NodePool that is doing the looping. This is the step to get right: adding a new, separate NodePool with the right startupTaints does not help, because the original pool still exists and still matches the pod, so it can keep being selected and keep looping. Edit the offending pool.

Two details that decide whether this works. Startup taints are matched on key and effect, so the effect you declare must match the effect actually applied — declaring NoExecute against a taint applied as NoSchedule will not match, and you stay in the loop. (Karpenter's own docs are a live example of the confusion: the NodePools page uses NoExecute for the Cilium taint while the FAQ uses NoSchedule for the same one.⁴¹) And startupTaints is one of the spec.template fields that feeds Karpenter's drift hash, so editing it on a live NodePool drifts every NodeClaim that pool owns — expect a rolling replacement of its nodes as the price of the fix. (Not every field behaves this way: changing requirements is treated as a special case and does not by itself drift nodes whose existing values remain compatible.⁷)

A complete, applyable NodePool — note that nodeClassRef and requirements are both required by the CRD, so the fragment shown in the docs will be rejected on its own:⁴

apiVersion: karpenter.sh/v1
kind: NodePool
metadata:
  name: default
spec:
  template:
    spec:
      nodeClassRef:
        group: karpenter.k8s.aws
        kind: EC2NodeClass
        name: default
      requirements:
        - key: kubernetes.io/arch
          operator: In
          values: ["amd64"]
      startupTaints:
        - key: node.cilium.io/agent-not-ready
          value: "true"
          effect: NoExecute

Karpenter applies startup taints to nodes it provisions, but does not require pods to tolerate them — it treats them as temporary and expects another system to remove them.⁴ The corollary matters for the next section: a node is not considered initialized until every startup taint declared in .spec.template.spec.startupTaints has been removed from the node's .spec.taints.²

Karpenter launched a node — why is my pod still Pending?

At this point the autoscaler has done its job and the problem has moved to node bootstrap or networking. Do not reason this out from scratch — the NodeClaim's own status conditions name the blocking step, with the offending taint or resource interpolated into the message:

kubectl get nodeclaim
kubectl get nodeclaim <name> -o jsonpath='{.status.conditions}'

Two conditions matter here and they fail for different reasons. Registered covers the earlier failure: the instance launched but never joined the cluster at all. The troubleshooting docs give three reasons a node can fail to join — permissions, security groups, and networking — and cover the diagnosis under Node NotReady, including how to pull kubelet logs over SSM.² Initialized covers what happens after it joins.

For initialization specifically, the docs name three factors: the node's Ready condition is True, all expected resources have registered to a non-zero quantity in .status.allocatable, and NodePool startup taints have been removed.² Two resources commonly fail to register: nvidia.com/gpu, when a GPU instance launches but the device-plugin DaemonSet that advertises the resource is absent, and vpc.amazonaws.com/pod-eni, when Karpenter expects it but ENABLE_POD_ENI is false in the VPC CNI.² Read the condition rather than working through the list by hand — the reason field tells you which of them tripped.

If the pod has moved to ContainerCreating rather than Pending, check IP allocation first — the aws-cni error reads failed to assign an IP address to container.² Two documented causes:

• maxPods exceeds the instance's supported pod density. If the maxPods you configured in the EC2NodeClass kubelet configuration is larger than the IPs the instance type supports, the CNI cannot assign one. The documented fixes are enabling prefix delegation, lowering maxPods, removing maxPods entirely to fall back on Karpenter and EKS AMI defaults, or setting RESERVED_ENIS=1 when using Security Groups for Pods.²
• Subnet IP exhaustion. EC2 launches the instance successfully because the subnet has room for an ENI, but there are no IPs left for pods. Documented fixes: topology spread on topology.kubernetes.io/zone, a larger subnet CIDR, custom networking, or an IPv6 cluster.²

One more that looks like a hang but is not: with Security Groups for Pods, pods requesting vpc.amazonaws.com/pod-eni can sit in ContainerCreating "for up to 30 minutes before transitioning to Running," an interaction with the amazon-vpc-resource-controller. The documented workaround is the vpc.amazonaws.com/has-trunk-attached: "false" label on the NodePool, with instance-type requirements restricted to types that support ENI trunking.²

Persistent volumes add their own scale-up failure. Karpenter does not support in-tree storage plugins, so a StorageClass provisioned by something like kubernetes.io/aws-ebs leaves Karpenter unable to discover volume-attachment limits — it logs that "Scale-ups may fail because Karpenter will not discover driver limits" and may believe a node has room it does not have.² Migrating to the CSI driver is the fix. Separately, a known Kubernetes race between the scheduler and CSINode registration can let the scheduler assume a node supports more volume attachments than it does; the aws-ebs-csi-driver and aws-efs-csi-driver both support a startup taint to eliminate it, configured through startupTaints on the NodePool.²

Why doesn't Karpenter scale up when a ResourceQuota is full?

Because there is no Pending pod. When a namespace's ResourceQuota is exhausted, Kubernetes rejects the creation request: "If creating or updating a resource violates a quota constraint, the control plane rejects that request with HTTP status code 403 Forbidden."⁸ The pod object is never created, so kube-scheduler never marks anything unschedulable, and Karpenter — which only acts on unschedulable pods¹ — has nothing to observe.

The symptom is distinctive: your Deployment's replica count never rises, and because the rejection lands on the controller doing the creating, the failure surfaces as a FailedCreate event on the ReplicaSet rather than on any pod.

This one is worth stating plainly rather than treating as a bug to be fixed: the behaviour is correct. A namespace quota is an administrative ceiling, and an autoscaler that provisioned past it would be defeating the control. There is a long-open request against the AWS provider asking Karpenter to scale in this situation, still open and filed against a pre-v1 version, but its stated "expected behaviour" amounts to asking the autoscaler to provision past the quota.⁹ Treat quota headroom as a prerequisite for autoscaling, not something autoscaling can resolve.

Why won't Karpenter scale up for a new DaemonSet — or for itself?

These are two documented refusals, and both are deliberate — neither is a bug to be worked around so much as a behaviour to design for.

DaemonSets. "Karpenter will not scale-up more capacity for an additional DaemonSet on its own," because the only pod that would land on the new node is the DaemonSet pod itself — capacity consumed for no benefit. DaemonSets are counted as overhead when sizing scale-ups for workload pods, but never as the reason for one. The documented workaround is to give DaemonSet pods a high priority with preemptionPolicy: PreemptLowerPriority, so they preempt lower-priority pods on existing nodes and push those pods into the Pending state that does trigger Karpenter.¹

Karpenter itself. "Karpenter won't launch capacity to run itself," which surfaces as a log line about the karpenter.sh/nodepool DoesNotExist requirement. Since version 0.16.0 the default replica count is 2, so a cluster with only enough non-Karpenter capacity for one controller pod leaves the second permanently Pending. The documented fixes are to reduce replicas back to 1, or to ensure there is enough capacity not managed by Karpenter to run both pods — on AWS, by raising the minimum and desired parameters on the node group's autoscaling group.²

A third case worth knowing before you file a bug: extra nodes that appear during a rollout and vanish shortly after may simply be maxSurge. Consolidation packs nodes tightly, so with a default 25% maxSurge the surge pods may have nowhere to run; Karpenter launches a node for them and removes it once it is no longer needed.¹

Why did Karpenter pick a node that turned out too small?

Because Karpenter models allocatable memory before the node exists, and the model has a deliberate fudge factor. For a new AMI and instance-type pair, it reduces instance memory by VM_MEMORY_OVERHEAD_PERCENT, whose default is 7.5% — "tuned to closely match reality for the majority of instance types while not overestimating."² After the first launch of that pair, Karpenter caches the observed capacity and uses the real number for subsequent nodes.

The direction of the error is the useful part: Karpenter "will typically underestimate the memory available on a node for a given instance type".² Underestimating is safe. Tuning the value down to tighten the bound is the risky direction — a value that causes overestimation "can result in Karpenter launching nodes which are too small for your workload."²

To detect it rather than infer it, watch the NodeClaim's ConsistentStateFound condition, which flips to False with reason ConsistencyCheckFailed:²

kubectl get nodeclaim $NODECLAIM_NAME \
  -o jsonpath='{.status.conditions[?(@.type=="ConsistentStateFound")]}'

The troubleshooting page gives operator_status_condition_count{type="ConsistentStateFound",kind="NodeClaim",status="False"} as the metric to monitor for this.² Note the tension with the metrics reference: that un-prefixed family is marked DEPRECATED, and the BETA per-kind equivalent is operator_nodeclaim_status_condition_count.⁶ Alert on the deprecated name if that is what your build emits, but expect to migrate.

The adjacent cause is under-specified pods rather than mis-modelled nodes. Karpenter bin-packs on resource requests, so pods with very low or missing requests get packed too densely, "resulting in the pods getting CPU throttled or terminated due to the OOM killer." The documented mitigation is per-namespace LimitRanges to enforce minimum request sizes.² This is not Karpenter-specific — kube-scheduler does the same thing with inaccurate requests — but Karpenter amplifies it by sizing the node to the same wrong number. If you are still deciding what those requests should be, in-place pod resizing gives you a way to change CPU and memory requests without restarting the pod while you measure.

Which metrics and logs should I check first?

Read the controller's ordinary logs first. Scheduling failures and NodePool exclusions are already written at info and error level, so you do not need to change any configuration to see them:

kubectl logs -n "${KARPENTER_NAMESPACE:-kube-system}" \
  -l app.kubernetes.io/name=karpenter -c controller --tail=200

Debug logging — the LOG_LEVEL environment variable, or --set logLevel=debug at install time² — is genuinely useful, but treat it as a second step rather than a reflex. Changing it requires restarting the deployment, and Karpenter provisions nothing until its cluster-state cache has re-synced after a restart. Restarting the autoscaler on a cluster that is already failing to scale is not where you want to begin.

Karpenter exposes Prometheus metrics at karpenter.kube-system.svc.cluster.local:8080/metrics, configurable via METRICS_PORT.⁶ Six carry most of the signal for scale-up investigations:⁶

Do not skip that last row. Cluster-state sync is a gate, not a curiosity: while it reads 0, Karpenter is not making provisioning decisions at all, so a cluster that has just restarted the controller or is churning heavily can look like every other failure on this list.

The none value on karpenter_scheduler_pending_pods_by_effective_zone_count is the one to alert on: it means the intersection of pod-level zone signals, PVC volume topology, and topology constraints is empty.⁶ That is a zonal contradiction inside the pod's own spec, and it turns a category of guesswork — "is this a zone problem?" — into a number you can graph.

Two stability notes so you do not build a dashboard on sand. Most of the useful scheduler metrics are labelled ALPHA rather than STABLE, and the metrics reference publishes a stability level for every metric precisely so you can tell which ones are safe to depend on.⁶ And the un-prefixed operator_status_condition_* family is marked DEPRECATED, while the per-kind variants — operator_nodepool_status_condition_count, operator_nodeclaim_status_condition_count, operator_ec2nodeclass_status_condition_count — are BETA.⁶

How is this different from Cluster Autoscaler?

The difference that matters for debugging is where the constraint lives. Rather than scaling a group you pre-defined, Karpenter derives the instance from the pending pods — which is why its failures present as requirement-intersection problems rather than a node group sitting at its maximum. It bin-packs the pending batch onto the smallest instance type that fits, then adds 59 larger types and passes all 60 options to EC2 Fleet, which selects using the Price Capacity Optimized allocation strategy.¹ A NodePool that permits only a handful of instance types starves that mechanism, so a required-offering error is worth checking against your own requirements before you conclude the capacity was not there.

Two operational differences follow. Karpenter "is not tied to a specific Kubernetes version, as the Cluster Autoscaler is," so you upgrade it on its own cadence¹ — though the compatibility matrix still sets a floor: Kubernetes 1.36 requires Karpenter 1.13 or later, 1.35 requires 1.9 or later, and 1.34 requires 1.6 or later.¹⁰ And these are not either/or choices: "Karpenter can work alongside Cluster Autoscaler," and NodePools are "designed to work alongside static capacity management solutions like EKS Managed Node Groups and EC2 Auto Scaling Groups."¹ If you are mid-migration, confirm which controller owns the pods you are debugging before assuming Karpenter is the one ignoring them.

Bottom line

Karpenter not scaling up nodes becomes tractable once you stop looking at the autoscaler and start looking at the gates in front of it. Run the sequence: start by reading the pod's events for Karpenter's own Failed to schedule pod message, which often names the cause outright and lets you skip the rest. If it is absent or unclear, work the gates in order — kubectl get nodepool and kubectl get ec2nodeclass for readiness, then status versus spec.limits, then the controller logs for the requirement-intersection message. Each of those either clears a gate or names the cause, which is why working them in order beats guessing.

Two habits prevent repeats. Declare every taint that lands on a node after launch as a startupTaint, because the alternative is a provisioning loop that costs real money. And keep NodePool requirements as wide as your workload genuinely tolerates — the docs recommend leaving instance-type requirements undefined because it "maximizes choices,"⁴ and separately note that the best defence against running out of spot capacity is to allow as many distinct instance types as possible.¹

For the deployment side of the same problem, our guide to zero-downtime deployments on Kubernetes covers the readiness and disruption settings that determine whether pods actually move onto the capacity Karpenter provisions, and the walkthrough of making helm upgrade --install idempotent is worth reading before your next Karpenter chart upgrade, since a partially applied release can leave NodePools unready. If you are debugging a different Kubernetes object stuck in a pending state, the same condition-reading discipline applies in our writeup on a cert-manager Certificate stuck in Pending.
